A mutable, format-neutral interface to a computational-graph model. More...

#include <graph_builder.hpp>

Detailed Description

Two-stage workflow: explore and configure a model (introspection, dynamic-dimension binding) with GraphBuilder, then freeze it into an immutable, evaluable Function.

GraphBuilder b("model.onnx");
b.bind_dim("batch", 4);
Function f = b.create("net");

Date: 2026

Extra doc: https://github.com/casadi/casadi/wiki/L_2jd

Definition at line 49 of file graph_builder.hpp.

Inheritance diagram for casadi::GraphBuilder:

[legend]

Collaboration diagram for casadi::GraphBuilder:

[legend]

Public Types
using	internal_base_type = SharedObjectInternal

using	base_type = SharedObject

Public Member Functions
std::string	type_name () const
	Readable name of the class. More...

	GraphBuilder ()
	Default constructor. More...

	GraphBuilder (const std::string &model_path, const Dict &opts=Dict())
	Construct from a model file (import lifecycle; format from the file suffix) More...

	GraphBuilder (const Function &f, const Dict &opts=Dict())
	Construct from a CasADi Function (export lifecycle) More...

	GraphBuilder (const std::string &name, const std::vector< uint8_t > &model_data, const std::string &format, const Dict &opts=Dict())
	Construct from model data in memory. More...

const std::string &	name () const
	Name of the model. More...

Function	create (const std::string &name, const std::vector< std::string > &name_in, const std::vector< std::string > &name_out, const Dict &opts=Dict()) const
	Freeze into an evaluable Function. More...

Function	create (const std::string &name, const Dict &opts=Dict()) const
	Freeze into an evaluable Function, exposing all model inputs and outputs. More...

Function	create () const
	Freeze into an evaluable Function, default naming. More...

void	export_onnx (const std::string &filename, const Dict &opts=Dict())
	Export to an ONNX model file. More...

std::string	class_name () const
	Get class name. More...

void	disp (std::ostream &stream, bool more=false) const
	Print a description of the object. More...

std::string	get_str (bool more=false) const
	Get string representation. More...

void	print_ptr (std::ostream &stream=casadi::uout()) const

void	own (SharedObjectInternal *node)

void	assign (SharedObjectInternal *node)
	Assign the node to a node class pointer without reference counting. More...

casadi_int	getCount () const
	Get the reference count. More...

void	swap (GenericShared &other)
	Swap content with another instance. More...

std::string	debug_repr () const

bool	is_null () const
	Is a null pointer? More...

casadi_int	__hash__ () const
	Returns a number that is unique for a given Node. More...

GenericWeakRef< SharedObject, SharedObjectInternal > *	weak ()
	Get a weak reference to the object. More...

Model introspection
casadi_int	n_in () const
	Declared shape of a tensor (input or output) by name; -1 for dynamic dimensions. More...

casadi_int	n_out () const
	Declared shape of a tensor (input or output) by name; -1 for dynamic dimensions. More...

std::vector< std::string >	name_in () const
	Declared shape of a tensor (input or output) by name; -1 for dynamic dimensions. More...

std::vector< std::string >	name_out () const
	Declared shape of a tensor (input or output) by name; -1 for dynamic dimensions. More...

std::vector< casadi_int >	dimension (const std::string &name) const
	Declared shape of a tensor (input or output) by name; -1 for dynamic dimensions. More...

std::string	dtype (const std::string &name) const
	Element type name of a tensor (input or output) by name (FLOAT, INT64, ...) More...

std::vector< std::string >	dimension_param (const std::string &name) const
	Per-axis symbolic dimension name of a tensor by name ("" for static axes) More...

std::vector< std::string >	dynamic_params () const
	Names of the symbolic/dynamic dimensions in the model. More...

Configuration
void	bind_dim (const std::string &param, casadi_int value)
	Bind a symbolic/dynamic dimension to a concrete size. More...

void	bind_shape (const std::string &input_name, const std::vector< casadi_int > &shape)
	Pin the full shape of an input. More...

void	set (const std::string &input_name, const std::vector< double > &value)
	Bake a fixed value into an input; it is fed at create() and not exposed as a Function input. More...

void	set (const std::string &input_name, double value)
	Bake a scalar value into an input. More...


GraphBuilderInternal *	operator-> ()

const GraphBuilderInternal *	operator-> () const

GraphBuilderInternal *	get () const

Protected Member Functions
void	count_up ()

void	count_down ()

Member Typedef Documentation

◆ base_type

using casadi::SharedObject::base_type = SharedObject

inherited

Definition at line 103 of file shared_object.hpp.

◆ internal_base_type

using casadi::SharedObject::internal_base_type = SharedObjectInternal

inherited

Definition at line 102 of file shared_object.hpp.

Constructor & Destructor Documentation

◆ GraphBuilder() [1/4]

casadi::GraphBuilder::GraphBuilder ( )

Definition at line 62 of file graph_builder.cpp.

62 {

63 }

◆ GraphBuilder() [2/4]

casadi::GraphBuilder::GraphBuilder	(	const std::string &	model_path,
		const Dict &	opts = `Dict()`
	)

explicit

Definition at line 65 of file graph_builder.cpp.

                                                                           {
     std::ifstream file(model_path, std::ios::binary | std::ios::ate);
     casadi_assert(file.is_open(), "Cannot open model file: " + model_path);
     std::streamsize size = file.tellg();
     file.seekg(0, std::ios::beg);
     std::vector<uint8_t> data(static_cast<size_t>(size));
     casadi_assert(file.read(reinterpret_cast<char*>(data.data()), size),
                   "Cannot read model file: " + model_path);
     own(new GraphBuilderInternal(model_path, data, format_from_path(model_path), opts));
   }

References casadi::format_from_path(), and casadi::GenericShared< SharedObject, SharedObjectInternal >::own().

◆ GraphBuilder() [3/4]

casadi::GraphBuilder::GraphBuilder	(	const Function &	f,
		const Dict &	opts = `Dict()`
	)

explicit

Definition at line 76 of file graph_builder.cpp.

                                                                 {
     own(new GraphBuilderInternal(f.name(), f, opts));
   }

References casadi::Function::name(), and casadi::GenericShared< SharedObject, SharedObjectInternal >::own().

◆ GraphBuilder() [4/4]

casadi::GraphBuilder::GraphBuilder	(	const std::string &	name,
		const std::vector< uint8_t > &	model_data,
		const std::string &	format,
		const Dict &	opts = `Dict()`
	)

Definition at line 80 of file graph_builder.cpp.

                                                                         {
     own(new GraphBuilderInternal(name, model_data, format, opts));
   }

References name(), and casadi::GenericShared< SharedObject, SharedObjectInternal >::own().

Member Function Documentation

◆ hash()

casadi_int casadi::GenericShared< SharedObject , SharedObjectInternal >::__hash__

inherited

If the Object does not point to any node, "0" is returned.

Extra doc: https://github.com/casadi/casadi/wiki/L_av

Definition at line 123 of file generic_shared_impl.hpp.

                                                              {
     return reinterpret_cast<casadi_int>(get());
   }

◆ assign()

void casadi::GenericShared< SharedObject , SharedObjectInternal >::assign ( Internal * node )

inherited

improper use will cause memory leaks!

Extra doc: https://github.com/casadi/casadi/wiki/L_at

Definition at line 96 of file generic_shared_impl.hpp.

                                                               {
     node = node_;
   }

◆ bind_dim()

void casadi::GraphBuilder::bind_dim	(	const std::string &	param,
		casadi_int	value
	)

Definition at line 117 of file graph_builder.cpp.

                                                                       {
     (*this)->bind_dim(param, value);
   }

◆ bind_shape()

void casadi::GraphBuilder::bind_shape	(	const std::string &	input_name,
		const std::vector< casadi_int > &	shape
	)

Definition at line 120 of file graph_builder.cpp.

                                                                     {
     (*this)->bind_shape(input_name, shape);
   }

◆ class_name()

std::string casadi::SharedObject::class_name ( ) const

inherited

Extra doc: https://github.com/casadi/casadi/wiki/L_au

Definition at line 31 of file shared_object.cpp.

                                            {
     return (*this)->class_name();
   }

Referenced by casadi::FmuFunction::check_mem_count(), casadi::MXFunction::export_code_body(), and casadi::BlazingSplineFunction::merge().

◆ count_down()

void casadi::GenericShared< SharedObject , SharedObjectInternal >::count_down

protectedinherited

Definition at line 133 of file generic_shared_impl.hpp.

                                                    {
 #ifdef WITH_EXTRA_CHECKS
     casadi_assert_dev(Function::call_depth_==0);
 #endif // WITH_EXTRA_CHECKS
     if (!node) return;
 #ifdef CASADI_WITH_THREADSAFE_SYMBOLICS
     GenericWeakRef<Shared, Internal>* weak_ref =
       node->weak_ref_.load(std::memory_order_acquire);
 #else
     GenericWeakRef<Shared, Internal>* weak_ref = node->weak_ref_;
 #endif // CASADI_WITH_THREADSAFE_SYMBOLICS
     if (weak_ref) {
 #ifdef CASADI_WITH_THREADSAFE_SYMBOLICS
       // get_mutex() returns a shared_ptr copy, so the mutex outlives this lock
       // even if delete node (below) destroys the WeakRefInternal holding it
       auto mutex = weak_ref->get_mutex();
       // Avoid triggering a delete while a weak_ref.shared_if_alive is being called
       std::lock_guard<std::mutex> lock(*mutex);
 #endif // CASADI_WITH_THREADSAFE_SYMBOLICS

       if (--static_cast<Internal*>(node)->count == 0) {
         delete node;
         node = nullptr;
       }
     } else {
       if (--static_cast<Internal*>(node)->count == 0) {
         delete node;
         node = nullptr;
       }
     }
   }

◆ count_up()

void casadi::GenericShared< SharedObject , SharedObjectInternal >::count_up

protectedinherited

Definition at line 132 of file generic_shared_impl.hpp.

                                                  {
 #ifdef WITH_EXTRA_CHECKS
     casadi_assert_dev(Function::call_depth_==0);
 #endif // WITH_EXTRA_CHECKS

     if (node) static_cast<Internal*>(node)->count++;

   }

◆ create() [1/3]

Function casadi::GraphBuilder::create ( ) const

inline

Extra doc: https://github.com/casadi/casadi/wiki/L_2jg

Definition at line 127 of file graph_builder.hpp.

127 { return create(name() + "_graph"); }

casadi::GraphBuilder::create

Function create() const

Freeze into an evaluable Function, default naming.

Definition: graph_builder.hpp:127

References create().

Referenced by create().

◆ create() [2/3]

Function casadi::GraphBuilder::create	(	const std::string &	name,
		const Dict &	opts = `Dict()`
	)		const

Parameters

name	Name assigned to the resulting Function
opts	See the full create() overload

Extra doc: https://github.com/casadi/casadi/wiki/L_2jf

Definition at line 137 of file graph_builder.cpp.

                                                                              {
     return (*this)->create_function(name, {}, {}, opts);
   }

References name().

◆ create() [3/3]

Function casadi::GraphBuilder::create	(	const std::string &	name,
		const std::vector< std::string > &	name_in,
		const std::vector< std::string > &	name_out,
		const Dict &	opts = `Dict()`
	)		const

Parameters

name	Name assigned to the resulting Function
name_in	Names of the inputs to expose (empty = all model inputs)
name_out	Names of the outputs to expose (empty = all model outputs)
opts	"symbolic" (bool, default false) and "backend" (numeric backend, default "ort"); any remaining options pass through to the backend.

Extra doc: https://github.com/casadi/casadi/wiki/L_2je

Definition at line 131 of file graph_builder.cpp.

                               {
     return (*this)->create_function(name, name_in, name_out, opts);
   }

References name(), name_in(), and name_out().

Referenced by casadi::DaeBuilderInternal::load_fmi_description().

◆ debug_repr()

std::string casadi::GenericShared< SharedObject , SharedObjectInternal >::debug_repr

inherited

Definition at line 112 of file generic_shared_impl.hpp.

                                                               {
     if (node) {
         return node->debug_repr(node);
     } else {
         return "NULL";
     }
   }

◆ dimension()

std::vector< casadi_int > casadi::GraphBuilder::dimension ( const std::string & name ) const

Definition at line 104 of file graph_builder.cpp.

                                                                            {
     return (*this)->node(name).dimension;
   }

References name().

◆ dimension_param()

std::vector< std::string > casadi::GraphBuilder::dimension_param ( const std::string & name ) const

Definition at line 110 of file graph_builder.cpp.

                                                                                 {
     return (*this)->node(name).dim_params;
   }

References name().

◆ disp()

void casadi::SharedObject::disp	(	std::ostream &	stream,
		bool	more = `false`
	)		const

inherited

Definition at line 35 of file shared_object.cpp.

                                                              {
     if (is_null()) {
       stream << "NULL";
     } else {
       (*this)->disp(stream, more);
     }
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::is_null().

Referenced by casadi::Nlpsol::disp_more(), and casadi::CsparseInterface::nfact().

◆ dtype()

std::string casadi::GraphBuilder::dtype ( const std::string & name ) const

Definition at line 107 of file graph_builder.cpp.

                                                            {
     return (*this)->node(name).dtype;
   }

References name().

◆ dynamic_params()

std::vector< std::string > casadi::GraphBuilder::dynamic_params ( ) const

Definition at line 113 of file graph_builder.cpp.

                                                           {
     return (*this)->dynamic_params();
   }

◆ export_onnx()

void casadi::GraphBuilder::export_onnx	(	const std::string &	filename,
		const Dict &	opts = `Dict()`
	)

Extra doc: https://github.com/casadi/casadi/wiki/L_2jh

Definition at line 140 of file graph_builder.cpp.

                                                                             {
     (*this)->export_onnx(filename, opts);
   }

References casadi::filename().

◆ get()

GraphBuilderInternal * casadi::GraphBuilder::get ( ) const

Access functions of the node

Definition at line 91 of file graph_builder.cpp.

                                                 {
     return static_cast<GraphBuilderInternal*>(SharedObject::get());
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::get().

Referenced by casadi::OnnxFunction::from_model_data().

◆ get_str()

std::string casadi::SharedObject::get_str ( bool more = false ) const

inlineinherited

Definition at line 91 of file shared_object.hpp.

                                                {
         std::stringstream ss;
         disp(ss, more);
         return ss.str();
       }

◆ getCount()

casadi_int casadi::GenericShared< SharedObject , SharedObjectInternal >::getCount

inherited

Definition at line 102 of file generic_shared_impl.hpp.

                                                              {
     return (*this)->getCount();
   }

◆ is_null()

bool casadi::GenericShared< SharedObject , SharedObjectInternal >::is_null

inherited

Definition at line 116 of file generic_shared_impl.hpp.

                                                       {
     return node==nullptr;
   }

◆ n_in()

casadi_int casadi::GraphBuilder::n_in ( ) const

Definition at line 100 of file graph_builder.cpp.

100 { return (*this)->n_in(); }

◆ n_out()

casadi_int casadi::GraphBuilder::n_out ( ) const

Definition at line 101 of file graph_builder.cpp.

101 { return (*this)->n_out(); }

◆ name()

const std::string & casadi::GraphBuilder::name ( ) const

Definition at line 95 of file graph_builder.cpp.

                                             {
     static std::string null = "null";
     return is_null() ? null : (*this)->name_;
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::is_null().

Referenced by create(), dimension(), dimension_param(), dtype(), and GraphBuilder().

◆ name_in()

std::vector< std::string > casadi::GraphBuilder::name_in ( ) const

Definition at line 102 of file graph_builder.cpp.

102 { return (*this)->name_in(); }

Referenced by create().

◆ name_out()

std::vector< std::string > casadi::GraphBuilder::name_out ( ) const

Definition at line 103 of file graph_builder.cpp.

103 { return (*this)->name_out(); }

Referenced by create().

◆ operator->() [1/2]

GraphBuilderInternal * casadi::GraphBuilder::operator-> ( )

Access functions of the node

Definition at line 85 of file graph_builder.cpp.

                                                  {
     return static_cast<GraphBuilderInternal*>(SharedObject::operator->());
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::operator->().

◆ operator->() [2/2]

const GraphBuilderInternal * casadi::GraphBuilder::operator-> ( ) const

Access functions of the node

Definition at line 88 of file graph_builder.cpp.

                                                              {
     return static_cast<const GraphBuilderInternal*>(SharedObject::operator->());
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::operator->().

◆ own()

void casadi::GenericShared< SharedObject , SharedObjectInternal >::own ( Internal * node )

inherited

Assign the node to a node class pointer (or null)

Definition at line 89 of file generic_shared_impl.hpp.

                                                            {
     count_down();
     node = node_;
     count_up();
   }

◆ print_ptr()

void casadi::SharedObject::print_ptr ( std::ostream & stream = casadi::uout() ) const

inherited

Print the pointer to the internal class

Definition at line 43 of file shared_object.cpp.

                                                        {
     stream << get();
   }

References casadi::GenericShared< SharedObject, SharedObjectInternal >::get().

◆ set() [1/2]

void casadi::GraphBuilder::set	(	const std::string &	input_name,
		const std::vector< double > &	value
	)

Definition at line 124 of file graph_builder.cpp.

                                                                                     {
     (*this)->set_value(input_name, value);
   }

◆ set() [2/2]

void casadi::GraphBuilder::set	(	const std::string &	input_name,
		double	value
	)

Definition at line 127 of file graph_builder.cpp.

                                                                   {
     (*this)->set_value(input_name, std::vector<double>(1, value));
   }

◆ swap()

void casadi::GenericShared< SharedObject , SharedObjectInternal >::swap ( GenericShared< SharedObject, SharedObjectInternal > & other )

inherited

Definition at line 105 of file generic_shared_impl.hpp.

                                                                  {
     GenericShared<Shared, Internal> temp = *this;
     *this = other;
     other = temp;
   }

◆ type_name()

std::string casadi::GraphBuilder::type_name ( ) const

inline

Definition at line 54 of file graph_builder.hpp.

54 { return "GraphBuilder"; }

◆ weak()

GenericWeakRef< SharedObject , SharedObjectInternal > * casadi::GenericShared< SharedObject , SharedObjectInternal >::weak

inherited

Extra doc: https://github.com/casadi/casadi/wiki/L_aw

Definition at line 130 of file generic_shared_impl.hpp.

                                                                           {
     return (*this)->weak();
   }

The documentation for this class was generated from the following files:

Detailed Description

Public Types

Public Member Functions

Protected Member Functions

Member Typedef Documentation

◆ base_type

◆ internal_base_type

Constructor & Destructor Documentation

◆ GraphBuilder() [1/4]

◆ GraphBuilder() [2/4]

◆ GraphBuilder() [3/4]

◆ GraphBuilder() [4/4]

Member Function Documentation

◆ __hash__()

◆ assign()

◆ bind_dim()

◆ bind_shape()

◆ class_name()

◆ count_down()

◆ count_up()

◆ create() [1/3]

◆ create() [2/3]

◆ create() [3/3]

◆ debug_repr()

◆ dimension()

◆ dimension_param()

◆ disp()

◆ dtype()

◆ dynamic_params()

◆ export_onnx()

◆ get()

◆ get_str()

◆ getCount()

◆ is_null()

◆ n_in()

◆ n_out()

◆ name()

◆ name_in()

◆ name_out()

◆ operator->() [1/2]

◆ operator->() [2/2]

◆ own()

◆ print_ptr()

◆ set() [1/2]

◆ set() [2/2]

◆ swap()

◆ type_name()

◆ weak()

◆ hash()
